Coil Strut Spacer

Coil Strut Spacer
INSTALLATION OF AUPART COIL STRUT SPACERS IS THE IDEAL WAY OF GENERATING LIFT ON VEHICLES WITH STRUT FRONT ENDS. COIL STRUT SPACERS BOLT TO THE TOP OF THE STRUT, AND MAINTAIN FULL ARTICULATION OF THE FRONT END. YOU CAN LIFT THE FRONT END TO EVEN OUT THE NOSE DIVE APPEARANCE WHILST STILL EMPLOYING STOCK SUSPENSION.
  • Product Feature
  • Product Specifications
Aupart Coil Strut Spacers kits includes a pair of coil strut spacers plus fitting hardware (studs, nuts etc.) The Strut Spacers are designed for vehicles running standard coil springs in the front. If your vehicle is fitted with a winch, bull bar etc., which is weighing the front end down, then a strut/spring upgrade is required.



Part Number Application Dimension
FORD/MAZDA/HOLDEN/ISUZU
AX0450 FORD RANGER 11-15, MAZDA BT-50 11-15,
HOLDEN COLORADO RG 12-16,
ISUZU D-MAX 12-16, ISUZU MU-X 13-on
10mm
AX0447 FORD RANGER 11-15, MAZDA BT-50 11-15,
HOLDEN COLORADO RG 12-16,
ISUZU D-MAX 12-16, ISUZU MU-X 13-on
15mm
AX0376 FORD RANGER 11-15, MAZDA BT-50 11-15,
HOLDEN COLORADO RG 12-16,
ISUZU D-MAX 12-16, ISUZU MU-X 13-on
25mm
AX0448 FORD RANGER 11-15, MAZDA BT-50 11-15,
HOLDEN COLORADO RG 12-16,
ISUZU D-MAX 12-16, ISUZU MU-X 13-on
35mm
AX0449 FORD RANGER 11-15, MAZDA BT-50 11-15,
HOLDEN COLORADO RG 12-16,
ISUZU D-MAX 12-16, ISUZU MU-X 13-on
50mm
MITSUBISHI
AX0511 MITSUBISHI TRITON ML/MN/MQ 06-on 10mm
AX0512 MITSUBISHI TRITON ML/MN/MQ 06-on 15mm
AX0514 MITSUBISHI TRITON ML/MN/MQ 06-on 25mm
AX0375 MITSUBISHI TRITON ML/MN/MQ 06-on 35mm
AX0513 MITSUBISHI TRITON ML/MN/MQ 06-on 50mm
NISSAN
AX0453 NISSAN NAVARA D40 08-15 10mm
AX0451 NISSAN NAVARA D40 08-15 15mm
AX0309 NISSAN NAVARA D40 08-15 25mm
AX0310 NISSAN NAVARA D40 08-15 35mm
AX0452 NISSAN NAVARA D40 08-15 50mm
TOYOTA
AX0450 TOYOTA LAND CRUISER 96-08, TOYOTA PRADO 95 SERIES 96-08 10mm
AX0447 TOYOTA LAND CRUISER 96-08, TOYOTA PRADO 95 SERIES 96-08 15mm
AX0376 TOYOTA LAND CRUISER 96-08, TOYOTA PRADO 95 SERIES 96-08 25mm
AX0448 TOYOTA LAND CRUISER 96-08, TOYOTA PRADO 95 SERIES 96-08 35mm
AX0449 TOYOTA LAND CRUISER 96-08, TOYOTA PRADO 95 SERIES 96-08 50mm
AX0455 TOYOTA LAND CRUISER 200 SERIES 08-15 10mm
AX0456 TOYOTA LAND CRUISER 200 SERIES 08-15 15mm
AX0457 TOYOTA LAND CRUISER 200 SERIES 08-15 25mm
AX0458 TOYOTA LAND CRUISER 200 SERIES 08-15 35mm
AX0413 TOYOTA LAND CRUISER 200 SERIES 08-15 50mm
AX0297 TOYOTA LAND CRUISER 02-on, TOYOTA HILUX 05-15 4WD, TOYOTA FJ CRUISER 06-on, TOYOTA PRADO 120/150 SERIES 10mm
AX0469 TOYOTA LAND CRUISER 02-on, TOYOTA HILUX 05-15 4WD, TOYOTA FJ CRUISER 06-on, TOYOTA PRADO 120/150 SERIES 15mm
AX0298 TOYOTA LAND CRUISER 02-on, TOYOTA HILUX 05-15 4WD, TOYOTA FJ CRUISER 06-on, TOYOTA PRADO 120/150 SERIES 25mm
AX0299 TOYOTA LAND CRUISER 02-on, TOYOTA HILUX 05-15 4WD, TOYOTA FJ CRUISER 06-on, TOYOTA PRADO 120/150 SERIES 35mm
AX0454 TOYOTA LAND CRUISER 02-on, TOYOTA HILUX 05-15 4WD, TOYOTA FJ CRUISER 06-on, TOYOTA PRADO 120/150 SERIES 50mm
